FEATURES |
Has intelligent microprocessor heat controllers that display both the set temperature and the actual temperature. |
| Has interchangable 3" silicone rubber coated laminating rollers |
60” wide film capacity |
| Includes metal stand |
Variable Speed: Max Mechanical Speed: 0 to 35 fpm. |
Made in the USA |
| Max overall laminating thickess = 1/2" |
| Top and bottom rollers are driven to minimize lamination curl |
| Has forced air cooling |
| Has reverse function |
Has built in Retractable Side Slitters
|
| Safety guard is built into the feed tray to insure use |
| Precision feed tray with right & left feed guides |
| Can hold 16" maximum diameter feed rolls |
| Includes 3" diameter core supply mandrels |
| Has dual tension knobs on each supply |
| Has removable teflon coated heat shoes for easy cleaning or roller replacement |
ACCESSORIES / OPTIONS |
Extra Slitter Head; item HDSH60: |
$78.95 with new machine purchase OR $114 separately
|
Release Liner Take-Up; item 7360000 or HD60RLTU: |
$2880 with new machine purchase OR $2990 separately
|
Footage Counter; item LEDFC: |
$699 with new machine purchase OR $749 separately |
ACCESSORIES / OPTIONS purchased separately here (Discounts shown above if purchased with new machine)
|
|
|
item# 7060200 for single phase OR 7060203A for 3-Phase
Prices start at $43,895
Ships FREE via freight in the lower 48 states & includes mandantory crating !
SPECIFICATIONS: |
Model: |
|
Width Capacity: |
|
Metal Stand: |
|
Electrical: |
220 volt, 7200 watts and 40 amps
|
Motor: |
|
Maximum Laminating Film Thickness: |
|
Max Film Roll Diameter: |
|
Dual Temperature Control |
|
Dimensions: |
|
Shipping Dimensions: |
|
Net Weight: |
|
Shipping Weight: |
|
Warranty: |
|
|
